Features:

This machine benchmarks against European LANCY technology and inherits the mature performance of JP series pumping spraying equipment, achieving integrated operation of forced mixing pumping spraying.
The whole machine is driven by an internal combustion engine, which provides strong and stable power; Equipped with an integrated hydraulic system, the working pressure, displacement, and stirring speed can be infinitely adjusted, ensuring stable and reliable operation. Equipped with a traction walking mechanism, the whole machine has a compact structure and flexible transition, suitable for outdoor work conditions without external power supply.
It can achieve continuous mixing, pumping, and spraying of mortar, effectively shorten the construction period, and support the transportation of large particle aggregate materials. Compatible with ordinary mortar, polymer mortar, plastering, insulation, bonding, fiber, self leveling, reinforcement filling mortar, and various grouting materials, it can complete spraying, filling, and long-distance pressure conveying operations.
The hydraulic system comes with overload protection, which is suitable for harsh working environments on construction sites. It is easy to disassemble and maintain vulnerable parts, and is suitable for outdoor infrastructure, road and bridge construction, mining and other projects without power grid supply.
Technical Parameters:

Model		JP60R
Rotor stator assembly		GL60（2L6）
Output		60L/min
Delivery pressure		30bar
Horizontal conevying distance		100m
Vertical conveying distance		50m
Motor power		21KW（柴油机Diesel）
Size	L	2850mm
	W	1220mm
	H	1080mm
Net weight		650kg
Adaptive components		Double layer steel wire wrapped rubber slurry pipe Φ50mm、Φ38mm、Φ32mm、Φ25mm，Φ13mm Options for gas pipelines.
